Square Proximity Sensor Switch (15mm Square)

Optimize the efficiency and reliability of your machinery with our Square Proximity Sensor Switch. This standard inductive sensor, encased in heat-resistant ABS resin, features a 15mm sensing surface and is designed for high-speed signal detection. Ideal for various industrial applications, it includes a detection indicator (red) and an NPN open collector output, ensuring easy installation and consistent performance.

• Specifications:
  • Type: Inductive Proximity Sensor
  • Shape: 15mm Square
  • Case Material: Heat-resistant ABS resin
  • Sensing Surface: 15mm
  • Indicator: Detection indicator (red)
  • Output: NPN open collector
  • Sensing Distance: 5mm
  • Voltage Range: 10-30 VDC
  • Mounting: Sensor face on the top, 90 degrees perpendicular to the mounting surface
  • Connection: 3-wire
    • Blue: GND
    • Brown: Source Voltage
    • Black: Signal
• Features:
  • Unshielded type
  • Detects ferrous metal objects
  • Surge suppressor
  • Power supply reverse polarity protection
  • High-speed signal detection
• Comparable Models: Omron TL-Q5MB1, TLQ5, TLQ5MC1, PUYON SN-04N, PS-05N, SS18-05DNA, Riko RN04-NP, Fotek PL-05N, Q05N
• Product Overview: Our Square Proximity Sensor Switch is perfect for various industrial applications requiring precise and reliable detection of ferrous metal objects. The heat-resistant ABS resin case ensures durability, while the easy-to-install design and high-speed signal detection make it a practical choice for enhancing your equipment's functionality.

Enhance the performance of your machinery with our reliable and efficient Square Proximity Sensor Switch!
